Engine Information

• Engine Type: 169CC, Air cooled, 4-stroke
• Start Type: Electric start
• Transmission: CVT automatic with reverse
• Max Torque: 9.3N.m/5500r/min
• Engine Gear: D-N-R (Fully Automatic with reverse)
• Shift Gear: Hand
• Ignition: CDI
• Fuel Capacity: 0.79 Gal
• Horse Power: 6.5 HP

Brakes and Suspension

• Brakes (Front & Rear): Hydraulic Disc
• Front Tire: 145 x 70-6
• Rear Tire: 16 x 6-8
• Front Suspension: Dual A-arms type
• Rear Suspension: Single Arm type
• With Adjustable Speed Limiter Control: Yes
• Engine Kill Switch: No

Battery and Weights

• Battery: 12V 9Ah (Included)
• Gross Weight: 638 lbs (290 kgs)
• Net Weight: 528 lbs (240 kgs)
• Max Loading: 320 lbs (160 kgs)

Dimensions

• Overall Size: 96 x 59 x 62 Inches (2450 x 1510 x 1580 mm)
• Ground Clearance: 5.9 Inches (150 mm)

Notes: Due to a recent manufacturer update, this vehicle no longer comes with color-matched seats. All colors come with black seats.
